SS1 series stainless steel casters with elastic rubber wheels

SAMPLE LEAD TIME

2–3 days

PRODUCTION LEAD TIME

10–30 days

CUSTOMIZATION

Yes

TECHNICAL SUPPORT

Drawings & spec sheets available

Browse Related Caster Options

SERIESSS1 series | 30-50 kg capacity

PRODUCT FAMILYStainless steel casters

WHEEL MATERIALElastic rubber

ALL PRODUCTSCaster WheelsView all products

Product Code / Configuration	Mounting Type	Wheel Ø (mm)	Wheel Width (mm)	Mounting Height (mm)	Offset (mm)	Top Plate Size (mm)	Bolt Hole Spacing (mm)	Bolt Hole Size (mm)	Threaded Stem (mm)	Load Capacity (kg) 4 km/h
SS1038ERSwivel	Top Plate	38	22	60	26	54x44	40x30	6.3		30
SS1050ERSwivel	Top Plate	50	22	70	23	54x44	40x30	6.3		50
SS1038ERFRigid	Top Plate	38	22	60	0	54x44	40x30	6.3		30
SS1050ERFRigid	Top Plate	50	22	70	0	54x44	40x30	6.3		50
SS1038ERBSwivel with Total Brake	Top Plate	38	22	60	26	54x44	40x30	6.3		30
SS1050ERBSwivel with Total Brake	Top Plate	50	22	70	23	54x44	40x30	6.3		50
SS1038ERTSwivel	Threaded Stem	38	22	60	26				M10x25	30
SS1050ERTSwivel	Threaded Stem	50	22	70	23				M10x25	50
SS1038ERTBSwivel with Total Brake	Threaded Stem	38	22	60	26				M10x25	30
SS1050ERTBSwivel with Total Brake	Threaded Stem	50	22	70	23				M10x25	50

Temperature Resistance	-20°C to +70°C
Rolling Resistance	Medium
Suitable Floor Surface	Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Wood, Asphalt
Suitable Floor Conditions	Smooth, Slightly Uneven, Uneven
