View all SS3 Euro-style series | 100-200 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|
| SS3080ERSwivel | Top Plate | 80 | 35 | 108 | 36 | 105x85 | 80x60 | 9x14 | 100 |
| SS3100ERSwivel | Top Plate | 100 | 36 | 128 | 35 | 105x85 | 80x60 | 9x14 | 140 |
| SS3125ERSwivel | Top Plate | 125 | 36 | 155 | 38 | 105x85 | 80x60 | 11x15 | 170 |
| SS3080ERFRigid | Top Plate | 80 | 35 | 108 | 0 | 105x85 | 80x60 | 9x14 | 100 |
| SS3100ERFRigid | Top Plate | 100 | 36 | 128 | 0 | 105x85 | 80x60 | 9x14 | 140 |
| SS3125ERFRigid | Top Plate | 125 | 36 | 155 | 0 | 105x85 | 80x60 | 11x15 | 170 |
| SS3080ERBSwivel with Total Brake | Top Plate | 80 | 35 | 108 | 36 | 105x85 | 80x60 | 9x14 | 100 |
| SS3100ERBSwivel with Total Brake | Top Plate | 100 | 36 | 128 | 35 | 105x85 | 80x60 | 9x14 | 140 |
| SS3125ERBSwivel with Total Brake | Top Plate | 125 | 36 | 155 | 38 | 105x85 | 80x60 | 11x15 | 170 |
| Wheel Construction | Tread on Core |
|---|---|
| Wheel Tread Material | Elastic rubber |
| Wheel Core Material | Polyamide 6 |
| Bearing Type | Ball Bearing, Roller Bearing |
| Bracket Material | Stainless Steel |
| Bracket Construction | Pressed |
| Salt Spray Test Duration | 100 h |
| Wheel Tread Hardness | 80 ± 5 Shore A |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Medium |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Wood, Natural Stone, Asphalt, Metal Grating |
| Suitable Floor Conditions | Smooth, Slightly Uneven, Uneven, With Obstacles |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
