View all SS2 series | 80-160 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Bolt Hole Fitting ⌀ (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SS2075SSSwivel | Top Plate | 75 | 32 | 105 | 34.5 | 95x64 | 74x45 | 8.5 | 100 | ||
| SS2100SSSwivel | Top Plate | 100 | 32 | 130 | 35 | 95x64 | 74x45 | 8.5 | 130 | ||
| SS2125SSSwivel | Top Plate | 125 | 32 | 155 | 30.5 | 95x64 | 74x45 | 8.5 | 160 | ||
| SS2075SSFRigid | Top Plate | 75 | 32 | 105 | 0 | 95x64 | 74x45 | 8.5 | 100 | ||
| SS2100SSFRigid | Top Plate | 100 | 32 | 130 | 0 | 95x64 | 74x45 | 8.5 | 130 | ||
| SS2125SSFRigid | Top Plate | 125 | 32 | 155 | 0 | 95x64 | 74x45 | 8.5 | 160 | ||
| SS2075SSBSwivel with Total Brake | Top Plate | 75 | 32 | 105 | 34.5 | 95x64 | 74x45 | 8.5 | 100 | ||
| SS2100SSBSwivel with Total Brake | Top Plate | 100 | 32 | 130 | 35 | 95x64 | 74x45 | 8.5 | 130 | ||
| SS2125SSBSwivel with Total Brake | Top Plate | 125 | 32 | 155 | 30.5 | 95x64 | 74x45 | 8.5 | 160 | ||
| SS2075SSTSwivel | Threaded Stem | 75 | 32 | 105 | 34.5 | M12x30 | 100 | ||||
| SS2100SSTSwivel | Threaded Stem | 100 | 32 | 130 | 35 | M12x30 | 130 | ||||
| SS2125SSTSwivel | Threaded Stem | 125 | 32 | 155 | 30.5 | M12x30 | 160 | ||||
| SS2075SSTBSwivel with Total Brake | Threaded Stem | 75 | 32 | 105 | 34.5 | M12x30 | 100 | ||||
| SS2100SSTBSwivel with Total Brake | Threaded Stem | 100 | 32 | 130 | 35 | M12x30 | 130 | ||||
| SS2125SSTBSwivel with Total Brake | Threaded Stem | 125 | 32 | 155 | 30.5 | M12x30 | 160 | ||||
| SS2075SSOSwivel | Bolt Hole | 75 | 32 | 105 | 34.5 | 13 | 100 | ||||
| SS2100SSOSwivel | Bolt Hole | 100 | 32 | 130 | 35 | 13 | 130 | ||||
| SS2125SSOSwivel | Bolt Hole | 125 | 32 | 155 | 30.5 | 13 | 160 | ||||
| SS2075SSOBSwivel with Total Brake | Bolt Hole | 75 | 32 | 105 | 34.5 | 13 | 100 | ||||
| SS2100SSOBSwivel with Total Brake | Bolt Hole | 100 | 32 | 130 | 35 | 13 | 130 | ||||
| SS2125SSOBSwivel with Total Brake | Bolt Hole | 125 | 32 | 155 | 30.5 | 13 | 160 |
| Wheel Construction | One-Piece |
|---|---|
| Wheel Material | Stainless steel |
| Bearing Type | Ball Bearing |
| Bracket Material | Stainless Steel |
| Bracket Construction | Pressed |
| Salt Spray Test Duration | 100 h |
| Wheel Tread Hardness | 180 HB |
| Temperature Resistance | -40°C to +300°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Asphalt, Metal Grating |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
| Suitable for Autoclaves | ✓ |
