View all SS1 series | 30-50 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|---|
| SS1040PASwivel | Top Plate | 40 | 20 | 60 | 26 | 54x44 | 40x30 | 6.3 | 30 | |
| SS1050PASwivel | Top Plate | 50 | 20 | 70 | 23 | 54x44 | 40x30 | 6.3 | 50 | |
| SS1040PAFRigid | Top Plate | 40 | 20 | 60 | 0 | 54x44 | 40x30 | 6.3 | 30 | |
| SS1050PAFRigid | Top Plate | 50 | 20 | 70 | 0 | 54x44 | 40x30 | 6.3 | 50 | |
| SS1040PABSwivel with Total Brake | Top Plate | 40 | 20 | 60 | 26 | 54x44 | 40x30 | 6.3 | 30 | |
| SS1050PABSwivel with Total Brake | Top Plate | 50 | 20 | 70 | 23 | 54x44 | 40x30 | 6.3 | 50 | |
| SS1040PATSwivel | Threaded Stem | 40 | 20 | 60 | 26 | M10x25 | 30 | |||
| SS1050PATSwivel | Threaded Stem | 50 | 20 | 70 | 23 | M10x25 | 50 | |||
| SS1040PATBSwivel with Total Brake | Threaded Stem | 40 | 20 | 60 | 26 | M10x25 | 30 | |||
| SS1050PATBSwivel with Total Brake | Threaded Stem | 50 | 20 | 70 | 23 | M10x25 | 50 |
| Wheel Construction | One-Piece |
|---|---|
| Wheel Material | Polyamide 6 |
| Bearing Type | Ball Bearing |
| Bracket Material | Stainless Steel |
| Bracket Construction | Pressed |
| Salt Spray Test Duration | 100 h |
| Wheel Tread Hardness | 65 ± 3 Shore D |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Carpet, Asphalt |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
