| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|---|
| L2038PVCSwivel | Top Plate | 38 | 22 | 61 | 20 | 64x43 | 45x30 | 6x9 | 40 | |
| L2050PVCSwivel | Top Plate | 50 | 25 | 72 | 20 | 70x51 | 53x34 | 8x11 | 50 | |
| L2065PVCSwivel | Top Plate | 65 | 32 | 96 | 35 | 94x64 | 74x45 | 8x11 | 100 | |
| L2038PVCFRigid | Top Plate | 38 | 22 | 61 | 0 | 64x43 | 45x30 | 6x9 | 40 | |
| L2050PVCFRigid | Top Plate | 50 | 25 | 72 | 0 | 70x51 | 53x34 | 8x11 | 50 | |
| L2065PVCFRigid | Top Plate | 65 | 32 | 96 | 0 | 94x64 | 74x45 | 8x11 | 100 | |
| L2038PVCBSwivel with Total Brake | Top Plate | 38 | 22 | 61 | 20 | 64x43 | 45x30 | 6x9 | 40 | |
| L2050PVCBSwivel with Total Brake | Top Plate | 50 | 25 | 72 | 20 | 70x51 | 53x34 | 8x11 | 50 | |
| L2065PVCBSwivel with Total Brake | Top Plate | 65 | 32 | 96 | 35 | 94x64 | 74x45 | 8x11 | 100 | |
| L2038PVCTSwivel | Threaded Stem | 38 | 22 | 61 | 20 | M8/M10x15/25 | 40 | |||
| L2050PVCTSwivel | Threaded Stem | 50 | 25 | 72 | 20 | M8/M10x15/25 | 50 | |||
| L2065PVCTSwivel | Threaded Stem | 65 | 32 | 96 | 35 | M8/M10x15/25 | 100 | |||
| L2038PVCTBSwivel with Total Brake | Threaded Stem | 38 | 22 | 61 | 20 | M8/M10x15/25 | 40 | |||
| L2050PVCTBSwivel with Total Brake | Threaded Stem | 50 | 25 | 72 | 20 | M8/M10x15/25 | 50 | |||
| L2065PVCTBSwivel with Total Brake | Threaded Stem | 65 | 32 | 96 | 35 | M8/M10x15/25 | 100 |
| Wheel Construction | Tread on Core |
|---|---|
| Wheel Tread Material | PVC |
| Wheel Core Material | Plastic |
| Bearing Type | Ball Bearing |
| Bracket Material | Steel |
| Bracket Construction | Pressed |
| Surface Treatment | E-Coated |
| Salt Spray Test Duration | 72 h |
| Wheel Tread Hardness | 95 ± 5 Shore A |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Carpet, Asphalt |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
