three heavy-duty caster wheels in top plate mounting style, with red tread black core wheel and dark green color metal bracket.

H3 series heavy-duty PU tread cast iron core caster wheels

SAMPLE LEAD TIME
2–3 days
PRODUCTION LEAD TIME
10–30 days
CUSTOMIZATION
Yes
TECHNICAL SUPPORT
Drawings & spec sheets available
Request a quote
View available models

Browse Related Caster Options

Model & Dimensions

Product Code / ConfigurationMounting TypeWheel Ø (mm)Wheel Width (mm)Mounting Height (mm)Offset (mm)Top Plate Size (mm)Bolt Hole Spacing (mm)Bolt Hole Size (mm)Load Capacity (kg)
4 km/h
H3100PUISwivelTop Plate1005015631140x110110x8112.5700
H3125PUISwivelTop Plate1255017841.5140x110110x8112.5800
H3150PUISwivelTop Plate1505020249140x110110x8112.5850
H3200PUISwivelTop Plate2005025350140x110110x8112.51000
H3100PUIFRigidTop Plate1005015631140x110110x8112.5700
H3125PUIFRigidTop Plate1255017841.5140x110110x8112.5800
H3150PUIFRigidTop Plate1505020249140x110110x8112.5850
H3200PUIFRigidTop Plate2005025350140x110110x8112.51000
H3100PUIBSwivel with Total BrakeTop Plate1005015631140x110110x8112.5700
H3125PUIBSwivel with Total BrakeTop Plate1255017841.5140x110110x8112.5800
H3150PUIBSwivel with Total BrakeTop Plate1505020249140x110110x8112.5850
H3200PUIBSwivel with Total BrakeTop Plate2005025350140x110110x8112.51000

Wheel & Bracket

Wheel ConstructionOne-Piece
Wheel Tread MaterialPU
Wheel Core MaterialCast iron
Bearing TypeDouble Ball Bearing
Bracket MaterialSteel
Bracket ConstructionWelded
Surface TreatmentPowder Coated
Salt Spray Test Duration120 h
Wheel Tread Hardness90 ± 5 Shore A

Performance & Environment

Temperature Resistance-20°C to +70°C
Rolling ResistanceMedium
Suitable Floor SurfaceConcrete, Resin / Epoxy, Tile, Vinyl / PVC, Asphalt
Suitable Floor ConditionsSmooth, Slightly Uneven, Uneven

Special Properties

Non-Marking✓
Non-Staining✓
Tread Hydrolysis-Resistant×
