Send your load, wheel size, mounting type and quantity for a faster recommendation.
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Load Capacity (kg) | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 km/h | 6 km/h | 10 km/h | Static | |||||||||
| EX7125PUISwivel | Top Plate | 125 | 50 | 170 | 50 | 140x110 | 105x75/80 | 11 | 450 | 310 | 180 | 1125 |
| EX7150PUISwivel | Top Plate | 150 | 50 | 200 | 55 | 140x110 | 105x75/80 | 11 | 570 | 380 | 200 | 1425 |
| EX7200PUISwivel | Top Plate | 200 | 80 | 255 | 65 | 175x140 | 140x105 | 14 | 1200 | 840 | 480 | 3000 |
| EX7250PUISwivel | Top Plate | 250 | 80 | 305 | 75 | 175x140 | 140x105 | 14 | 1400 | 900 | 560 | 3500 |
| EX7300PUISwivel | Top Plate | 300 | 100 | 370 | 85 | 200x160 | 160x120 | 14 | 2250 | 1250 | 840 | 5625 |
| EX7125PUIFRigid | Top Plate | 125 | 50 | 170 | 50 | 140x110 | 105x75/80 | 11 | 450 | 310 | 180 | 1125 |
| EX7150PUIFRigid | Top Plate | 150 | 50 | 200 | 55 | 140x110 | 105x75/80 | 11 | 570 | 380 | 200 | 1425 |
| EX7200PUIFRigid | Top Plate | 200 | 80 | 255 | 65 | 175x140 | 140x105 | 14 | 1200 | 840 | 480 | 3000 |
| EX7250PUIFRigid | Top Plate | 250 | 80 | 305 | 75 | 175x140 | 140x105 | 14 | 1400 | 900 | 560 | 3500 |
| EX7300PUIFRigid | Top Plate | 300 | 100 | 370 | 85 | 200x160 | 160x120 | 14 | 2250 | 1250 | 840 | 5625 |
| EX7125PUIBSwivel with Total Brake | Top Plate | 125 | 50 | 170 | 50 | 140x110 | 105x75/80 | 11 | 450 | 310 | 180 | 1125 |
| EX7150PUIBSwivel with Total Brake | Top Plate | 150 | 50 | 200 | 55 | 140x110 | 105x75/80 | 11 | 570 | 380 | 200 | 1425 |
| EX7200PUIBSwivel with Total Brake | Top Plate | 200 | 80 | 255 | 65 | 175x140 | 140x105 | 14 | 1200 | 840 | 480 | 3000 |
| EX7250PUIBSwivel with Total Brake | Top Plate | 250 | 80 | 305 | 75 | 175x140 | 140x105 | 14 | 1400 | 900 | 560 | 3500 |
| EX7300PUIBSwivel with Total Brake | Top Plate | 300 | 100 | 370 | 85 | 200x160 | 160x120 | 14 | 2250 | 1250 | 840 | 5625 |
| Wheel Construction | Tread on Core |
|---|---|
| Wheel Tread Material | PU |
| Wheel Core Material | Cast iron |
| Bearing Type | Double Ball Bearing |
| Bracket Material | Steel |
| Bracket Construction | Welded |
| Surface Treatment | Yellow Zinc Plated |
| Salt Spray Test Duration | 48 h |
| Wheel Tread Hardness | 75 ± 3 Shore A |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Antistatic | ✓ |
|---|---|
| Conductive | ✓ |
| Non-Marking | ✓ |
| Non-Staining | ✓ |
| Tread Hydrolysis-Resistant | ✓ |
| Suitable for Autoclaves | ✓ |
| Suitable for Machine Washing | ✓ |
