Three heavy-duty caster wheels in top plate mounting style, with red tread silver core wheel and black color metal bracket.

EX3 series extra heavy-duty casters with PU tread cast iron core wheel

SAMPLE LEAD TIME
5–7 days
PRODUCTION LEAD TIME
30–40 days
CUSTOMIZATION
Yes
TECHNICAL SUPPORT
Drawings & spec sheets available
Request a quote
View available models

Browse Related Caster Options

Model & Dimensions

Product Code / ConfigurationMounting TypeWheel Ø (mm)Wheel Width (mm)Mounting Height (mm)Offset (mm)Top Plate Size (mm)Bolt Hole Spacing (mm)Bolt Hole Size (mm)Load Capacity (kg)
4 km/h
EX3150PUISwivelTop Plate1507520454.5170x125135x8514x301200
EX3200PUISwivelTop Plate2007525260170x125135x8514x301500
EX3250PUISwivelTop Plate2507530576170x125135x8514x301800
EX3300PUISwivelTop Plate3007536297170x125135x8514x302000
EX3150PUIFRigidTop Plate1507520454.5170x125135x8514x301200
EX3200PUIFRigidTop Plate2007525260170x125135x8514x301500
EX3250PUIFRigidTop Plate2507530576170x125135x8514x301800
EX3300PUIFRigidTop Plate3007536297170x125135x8514x302000
EX3150PUIBSwivelTop Plate1507520454.5170x125135x8514x301200
EX3200PUIBSwivelTop Plate2007525260170x125135x8514x301500
EX3250PUIBSwivelTop Plate2507530576170x125135x8514x301800
EX3300PUIBSwivelTop Plate3007536297170x125135x8514x302000

Wheel & Bracket

Wheel ConstructionTread on Core
Wheel Tread MaterialPU
Wheel Core MaterialCast iron
Bearing TypeDouble Ball Bearing
Bracket MaterialSteel
Bracket ConstructionWelded
Surface TreatmentPowder Coated
Salt Spray Test Duration72 h
Wheel Tread Hardness95 ± 5 Shore A

Performance & Environment

Temperature Resistance-20°C to +70°C
Rolling ResistanceMedium
Suitable Floor SurfaceConcrete, Resin / Epoxy, Tile, Vinyl / PVC, Asphalt
Suitable Floor ConditionsSmooth, Slightly Uneven

Special Properties

Non-Marking✓
Non-Staining✓
Tread Hydrolysis-Resistant×

Related Products

Two heavy-duty caster wheels in top plate mounting style, with red tread black core wheel and dark green color metal bracket.EX4 series extra heavy-duty casters with PU tread cast iron core wheelOverlapping load range: 1,200 - 2,000 kgView product →Three heavy-duty caster wheels in top plate mounting style, with green tread silver core wheel and golden color metal bracket.EX7 series extra heavy-duty casters with PU tread cast iron core wheelOverlapping load range: 1,200 - 2,000 kgView product →Three heavy-duty caster wheels in top plate mounting style, with green tread silver core wheel and golden color metal bracket.EX7D series extra heavy-duty dual wheel PU tread cast iron core castersOverlapping load range: 1,200 - 2,000 kgView product →Three heavy-duty caster wheels in top plate mounting style, with brown tread silver core wheel and golden color metal bracket.EX8 series extra heavy-duty PU tread cast iron core castersOverlapping load range: 1,200 - 2,000 kgView product →
