heavy-duty european style casters with blue rubber tread wheels in top-plate rigid, swivel and swivel with brake configurations.

H4EU series euro-style heavy-duty elastic rubber caster wheels

Request a quote
View available models

Send your load, wheel size, mounting type and quantity for a faster recommendation.

SERIESH4EU Euro-style series | 200-550 kg capacity SeriesView all H4EU Euro-style series | 200-550 kg capacity castersPRODUCT FAMILYVersatile heavy-duty castersView all Versatile heavy-duty castersWHEEL MATERIALElastic rubberView all casters with Elastic rubber wheelsALL PRODUCTSCaster WheelsView all products

Model & Dimensions

Product Code / ConfigurationMounting TypeWheel Ø (mm)Wheel Width (mm)Mounting Height (mm)Offset (mm)Top Plate Size (mm)Bolt Hole Spacing (mm)Bolt Hole Size (mm)Load Capacity (kg)
4 km/h
H4EU100ERSwivelTop Plate1003612843105x8280x609200
H4EU125ERSwivelTop Plate1253615343105x8280x609300
H4EU160ERSwivelTop Plate1605019768135x105105x8011400
H4EU200ERSwivelTop Plate2005024068135x105105x8011550
H4EU100ERFRigidTop Plate100361280105x8280x609200
H4EU125ERFRigidTop Plate125361530105x8280x609300
H4EU160ERFRigidTop Plate160501970135x105105x8011400
H4EU200ERFRigidTop Plate20050680135x105105x8011550
H4EU100ERBSwivel with Total BrakeTop Plate1003612843105x8280x609200
H4EU125ERBSwivel with Total BrakeTop Plate1253615343105x8280x609300
H4EU160ERBSwivel with Total BrakeTop Plate1605019768135x105105x8011400
H4EU200ERBSwivel with Total BrakeTop Plate2005024068135x105105x8011550
H4EU160ERRBSwivel with Rare Total BrakeTop Plate1605019750135x105105x8011400
H4EU200ERRBSwivel with Rare Total BrakeTop Plate2005024056135x105105x8011550

Wheel & Bracket

Wheel ConstructionTread on Core
Wheel Tread MaterialElastic rubber
Wheel Core MaterialPolyamide 6
Bearing TypeDouble Ball Bearing
Bracket MaterialSteel
Bracket ConstructionPressed
Surface TreatmentWhite Zinc Plated
Salt Spray Test Duration48 h
Wheel Tread Hardness75 ± 5 Shore A

Performance & Environment

Temperature Resistance-20°C to +70°C
Rolling ResistanceMedium
Suitable Floor SurfaceConcrete, Resin / Epoxy, Tile, Vinyl / PVC, Wood, Asphalt
Suitable Floor ConditionsSmooth, Slightly Uneven, Uneven

Special Properties

Non-Marking✓
Non-Staining✓
