heavy duty american-style casters with blue rubber tread wheels in top-plate rigid, swivel and swivel with brake configurations

H1 series heavy-duty elastic rubber caster wheels

Send your load, wheel size, mounting type and quantity for a faster recommendation.

SERIESH1 series | 150-460 kg capacity SeriesView all H1 series | 150-460 kg capacity casters PRODUCT FAMILYVersatile heavy-duty castersView all Versatile heavy-duty casters WHEEL MATERIALElastic rubberView all casters with Elastic rubber wheels ALL PRODUCTSCaster WheelsView all products

Model & Dimensions

Product Code / Configuration	Mounting Type	Wheel Ø (mm)	Wheel Width (mm)	Mounting Height (mm)	Offset (mm)	Top Plate Size (mm)	Bolt Hole Spacing (mm)	Bolt Hole Size (mm)	Load Capacity (kg) 4 km/h
H1100ERSwivel	Top Plate	100	50	143	36.5	115x100	84x70	11x20	150
H1125ERSwivel	Top Plate	125	50	165	42	115x100	84x70	11x20	250
H1150ERSwivel	Top Plate	150	50	190	51	115x100	84x70	11x20	300
H1200ERSwivel	Top Plate	200	50	241	63	115x100	84x70	11x20	350
H1100ERFRigid	Top Plate	100	50	143	0	115x100	84x70	11x20	150
H1125ERFRigid	Top Plate	125	50	165	0	115x100	84x70	11x20	250
H1150ERFRigid	Top Plate	150	50	190	0	115x100	84x70	11x20	300
H1200ERFRigid	Top Plate	200	50	241	0	115x100	84x70	11x20	350
H1100ERSBSwivel with Side-Mounted Wheel Brake	Top Plate	100	50	143	36.5	115x100	84x70	11x20	150
H1125ERSBSwivel with Side-Mounted Wheel Brake	Top Plate	125	50	165	42	115x100	84x70	11x20	250
H1150ERSBSwivel with Side-Mounted Wheel Brake	Top Plate	150	50	190	51	115x100	84x70	11x20	300
H1200ERSBSwivel with Side-Mounted Wheel Brake	Top Plate	200	50	241	63	115x100	84x70	11x20	350
H1100ERTBSwivel with Total Brake	Top Plate	100	50	143	36.5	115x100	84x70	11x20	150
H1125ERTBSwivel with Total Brake	Top Plate	125	50	165	42	115x100	84x70	11x20	250
H1150ERTBSwivel with Total Brake	Top Plate	150	50	190	51	115x100	84x70	11x20	300
H1200ERTBSwivel with Total Brake	Top Plate	200	50	241	63	115x100	84x70	11x20	350

Wheel & Bracket

Wheel Construction	Tread on Core
Wheel Tread Material	Elastic rubber
Wheel Core Material	Polyamide 6
Bearing Type	Double Ball Bearing, Roller Bearing
Bracket Material	Steel
Bracket Construction	Welded
Surface Treatment	White Zinc Plated
Salt Spray Test Duration	48 h
Wheel Tread Hardness	8 ± 5 Shore A

Performance & Environment

Temperature Resistance	-20°C to +70°C
Rolling Resistance	Medium
Suitable Floor Surface	Concrete, Resin / Epoxy, Tile, Vinyl / PVC
Suitable Floor Conditions	Smooth, Slightly Uneven, Uneven, With Obstacles

Special Properties

Non-Marking	✓
Non-Staining	✓
