View all H1 series | 150-460 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|
| H1100PPSwivel | Top Plate | 100 | 50 | 143 | 36.5 | 115x100 | 84x70 | 11x20 | 260 |
| H1125PPSwivel | Top Plate | 125 | 50 | 165 | 42 | 115x100 | 84x70 | 11x20 | 320 |
| H1150PPSwivel | Top Plate | 150 | 50 | 190 | 51 | 115x100 | 84x70 | 11x20 | 380 |
| H1200PPSwivel | Top Plate | 200 | 50 | 241 | 63 | 115x100 | 84x70 | 11x20 | 460 |
| H1100PPFRigid | Top Plate | 100 | 50 | 143 | 0 | 115x100 | 84x70 | 11x20 | 260 |
| H1125PPFRigid | Top Plate | 125 | 50 | 165 | 0 | 115x100 | 84x70 | 11x20 | 320 |
| H1150PPFRigid | Top Plate | 150 | 50 | 190 | 0 | 115x100 | 84x70 | 11x20 | 380 |
| H1200PPFRigid | Top Plate | 200 | 50 | 241 | 0 | 115x100 | 84x70 | 11x20 | 460 |
| H1100PPSBSwivel with Side-Mounted Wheel Brake | Top Plate | 100 | 50 | 143 | 36.5 | 115x100 | 84x70 | 11x20 | 260 |
| H1125PPSBSwivel with Side-Mounted Wheel Brake | Top Plate | 125 | 50 | 165 | 42 | 115x100 | 84x70 | 11x20 | 320 |
| H1150PPSBSwivel with Side-Mounted Wheel Brake | Top Plate | 150 | 50 | 190 | 51 | 115x100 | 84x70 | 11x20 | 380 |
| H1200PPSBSwivel with Side-Mounted Wheel Brake | Top Plate | 200 | 50 | 241 | 63 | 115x100 | 84x70 | 11x20 | 460 |
| H1100PPTBSwivel with Total Brake | Top Plate | 100 | 50 | 143 | 36.5 | 115x100 | 84x70 | 11x20 | 260 |
| H1125PPTBSwivel with Total Brake | Top Plate | 125 | 50 | 165 | 42 | 115x100 | 84x70 | 11x20 | 320 |
| H1150PPTBSwivel with Total Brake | Top Plate | 150 | 50 | 190 | 51 | 115x100 | 84x70 | 11x20 | 380 |
| H1200PPTBSwivel with Total Brake | Top Plate | 200 | 50 | 241 | 63 | 115x100 | 84x70 | 11x20 | 460 |
| Wheel Construction | One-Piece |
|---|---|
| Wheel Material | Plastic |
| Bearing Type | Double Ball Bearing |
| Bracket Material | Steel |
| Bracket Construction | Welded |
| Surface Treatment | White Zinc Plated |
| Salt Spray Test Duration | 48 h |
| Wheel Tread Hardness | 65 ± 2 Shore D |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
