View all M2EU Euro-style series | 80-300 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Bolt Hole Fitting ⌀ (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M2EU080TPRSwivel | Top Plate | 80 | 36 | 108 | 38 | 105x80 | 80x60 | 11x9 | 140 | ||
| M2EU100TPRSwivel | Top Plate | 100 | 36 | 128 | 38 | 105x80 | 80x60 | 11x9 | 170 | ||
| M2EU125TPRSwivel | Top Plate | 125 | 36 | 155 | 38 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU080TPRFRigid | Top Plate | 80 | 36 | 108 | 0 | 105x80 | 80x60 | 11x9 | 140 | ||
| M2EU100TPRFRigid | Top Plate | 100 | 36 | 128 | 0 | 105x80 | 80x60 | 11x9 | 170 | ||
| M2EU125TPRFRigid | Top Plate | 125 | 36 | 155 | 0 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU080TPRBSwivel with Total Brake | Top Plate | 80 | 36 | 108 | 38 | 105x80 | 80x60 | 11x9 | 140 | ||
| M2EU100TPRBSwivel with Total Brake | Top Plate | 100 | 36 | 128 | 38 | 105x80 | 80x60 | 11x9 | 170 | ||
| M2EU125TPRBSwivel with Total Brake | Top Plate | 125 | 36 | 155 | 38 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU080TPRTSwivel | Threaded Stem | 80 | 36 | 108 | 38 | M10/M12 x30 | 140 | ||||
| M2EU100TPRTSwivel | Threaded Stem | 100 | 36 | 128 | 38 | M10/M12 x30 | 170 | ||||
| M2EU125TPRTSwivel | Threaded Stem | 125 | 36 | 155 | 38 | M10/M12 x30 | 180 | ||||
| M2EU080TPRTBSwivel with Total Brake | Threaded Stem | 80 | 36 | 108 | 38 | M10/M12 x30 | 140 | ||||
| M2EU100TPRTBSwivel with Total Brake | Threaded Stem | 100 | 36 | 128 | 38 | M10/M12 x30 | 170 | ||||
| M2EU125TPRTBSwivel with Total Brake | Threaded Stem | 125 | 36 | 155 | 38 | M10/M12 x30 | 180 | ||||
| M2EU080TPROSwivel | Bolt Hole | 80 | 36 | 108 | 38 | 10/12 | 140 | ||||
| M2EU100TPROSwivel | Bolt Hole | 100 | 36 | 128 | 38 | 10/12 | 170 | ||||
| M2EU125TPROSwivel | Bolt Hole | 125 | 36 | 155 | 38 | 10/12 | 180 | ||||
| M2EU080TPROBSwivel with Total Brake | Bolt Hole | 80 | 36 | 108 | 38 | 10/12 | 140 | ||||
| M2EU100TPROBSwivel with Total Brake | Bolt Hole | 100 | 36 | 128 | 38 | 10/12 | 170 | ||||
| M2EU125TPROBSwivel with Total Brake | Bolt Hole | 125 | 36 | 155 | 38 | 10/12 | 180 |
| Wheel Construction | Tread on Core |
|---|---|
| Wheel Tread Material | TPR |
| Wheel Core Material | Plastic |
| Bearing Type | Ball Bearing |
| Bracket Material | Steel |
| Bracket Construction | Pressed |
| Surface Treatment | White Zinc Plated |
| Salt Spray Test Duration | 48 h |
| Wheel Tread Hardness | 80 ± 5 Shore A |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Medium |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Wood |
| Suitable Floor Conditions | Smooth, Slightly Uneven, Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
