View all M2EU Euro-style series | 80-300 kg capacity casters
| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Bolt Hole Fitting ⌀ (mm) | Load Capacity (kg) 4 km/h |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M2EU080UASwivel | Top Plate | 80 | 32 | 108 | 38 | 105x80 | 80x60 | 11x9 | 120 | ||
| M2EU100UASwivel | Top Plate | 100 | 32 | 128 | 38 | 105x80 | 80x60 | 11x9 | 150 | ||
| M2EU125UASwivel | Top Plate | 125 | 40 | 155 | 38 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU160UASwivel | Top Plate | 160 | 50 | 190 | 52 | 135x110 | 105x80 | 13.5x11 | 250 | ||
| M2EU200UASwivel | Top Plate | 200 | 50 | 235 | 54 | 135x110 | 105x80 | 13.5x11 | 300 | ||
| M2EU080UAFRigid | Top Plate | 80 | 32 | 108 | 0 | 105x80 | 80x60 | 11x9 | 120 | ||
| M2EU100UAFRigid | Top Plate | 100 | 32 | 128 | 0 | 105x80 | 80x60 | 11x9 | 150 | ||
| M2EU125UAFRigid | Top Plate | 125 | 40 | 155 | 0 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU160UAFRigid | Top Plate | 160 | 50 | 190 | 0 | 135x110 | 105x80 | 13.5x11 | 250 | ||
| M2EU200UAFRigid | Top Plate | 200 | 50 | 235 | 0 | 135x110 | 105x80 | 13.5x11 | 300 | ||
| M2EU080UABSwivel with Total Brake | Top Plate | 80 | 32 | 108 | 38 | 105x80 | 80x60 | 11x9 | 120 | ||
| M2EU100UABSwivel with Total Brake | Top Plate | 100 | 32 | 128 | 38 | 105x80 | 80x60 | 11x9 | 150 | ||
| M2EU125UABSwivel with Total Brake | Top Plate | 125 | 40 | 155 | 38 | 105x80 | 80x60 | 11x9 | 180 | ||
| M2EU160UABSwivel with Total Brake | Top Plate | 160 | 50 | 190 | 52 | 135x110 | 105x80 | 13.5x11 | 250 | ||
| M2EU200UABSwivel with Total Brake | Top Plate | 200 | 50 | 235 | 54 | 135x110 | 105x80 | 13.5x11 | 300 | ||
| M2EU080UATSwivel | Threaded Stem | 80 | 32 | 108 | 38 | M10/M12 x30 | 120 | ||||
| M2EU100UATSwivel | Threaded Stem | 100 | 32 | 128 | 38 | M10/M12 x30 | 150 | ||||
| M2EU125UATSwivel | Threaded Stem | 125 | 40 | 155 | 38 | M10/M12 x30 | 180 | ||||
| M2EU160UATSwivel | Threaded Stem | 160 | 50 | 190 | 52 | M10/M12 x30 | 250 | ||||
| M2EU200UATSwivel | Threaded Stem | 200 | 50 | 235 | 54 | M10/M12 x30 | 300 | ||||
| M2EU080UATBSwivel with Total Brake | Threaded Stem | 80 | 32 | 108 | 38 | M10/M12 x30 | 120 | ||||
| M2EU100UATBSwivel with Total Brake | Threaded Stem | 100 | 32 | 128 | 38 | M10/M12 x30 | 150 | ||||
| M2EU125UATBSwivel with Total Brake | Threaded Stem | 125 | 40 | 155 | 38 | M10/M12 x30 | 180 | ||||
| M2EU160UATBSwivel with Total Brake | Threaded Stem | 160 | 50 | 190 | 52 | M10/M12 x30 | 250 | ||||
| M2EU200UATBSwivel with Total Brake | Threaded Stem | 200 | 50 | 235 | 54 | M10/M12 x30 | 300 | ||||
| M2EU080UAOSwivel | Bolt Hole | 80 | 32 | 108 | 38 | 10/12/16 | 120 | ||||
| M2EU100UAOSwivel | Bolt Hole | 100 | 32 | 128 | 38 | 10/12/16 | 150 | ||||
| M2EU125UAOSwivel | Bolt Hole | 125 | 40 | 155 | 38 | 10/12/16 | 180 | ||||
| M2EU160UAOSwivel | Bolt Hole | 160 | 50 | 190 | 52 | 10/12/16 | 250 | ||||
| M2EU200UAOSwivel | Bolt Hole | 200 | 50 | 235 | 54 | 10/12/16 | 300 | ||||
| M2EU080UAOBSwivel with Total Brake | Bolt Hole | 80 | 32 | 108 | 38 | 10/12/16 | 120 | ||||
| M2EU100UAOBSwivel with Total Brake | Bolt Hole | 100 | 32 | 128 | 38 | 10/12/16 | 150 | ||||
| M2EU125UAOBSwivel with Total Brake | Bolt Hole | 125 | 40 | 155 | 38 | 10/12/16 | 180 | ||||
| M2EU160UAOBSwivel with Total Brake | Bolt Hole | 160 | 50 | 190 | 52 | 10/12/16 | 250 | ||||
| M2EU200UAOBSwivel with Total Brake | Bolt Hole | 200 | 50 | 235 | 54 | 10/12/16 | 300 |
| Wheel Construction | Tread on Core |
|---|---|
| Wheel Tread Material | PU |
| Wheel Core Material | Aluminum |
| Bearing Type | Double Ball Bearing |
| Bracket Material | Steel |
| Bracket Construction | Pressed |
| Surface Treatment | White Zinc Plated |
| Salt Spray Test Duration | 48 h |
| Wheel Tread Hardness | 90 ± 5 Shore A |
| Temperature Resistance | -20°C to +70°C |
|---|---|
| Rolling Resistance | Medium |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Asphalt |
| Suitable Floor Conditions | Smooth, Slightly Uneven, Uneven |
| Non-Marking | ✓ |
|---|---|
| Non-Staining | ✓ |
| Tread Hydrolysis-Resistant | × |
