Three casters with black rubber tread black plastic core wheels in top-plate rigid, swivel and swivel with brake configurations.

M2 series standard medium-duty plastic rim rubber caster wheels

Send your load, wheel size, mounting type and quantity for a faster recommendation.

SERIESM2 Standard series | 50-230 kg capacity SeriesView all M2 Standard series | 50-230 kg capacity casters PRODUCT FAMILYVersatile medium-duty castersView all Versatile medium-duty casters WHEEL MATERIALBlack rubberView all casters with Black rubber wheels ALL PRODUCTSCaster WheelsView all products

Model & Dimensions

Product Code / Configuration	Mounting Type	Wheel Ø (mm)	Wheel Width (mm)	Mounting Height (mm)	Offset (mm)	Top Plate Size (mm)	Bolt Hole Spacing (mm)	Bolt Hole Size (mm)	Threaded Stem (mm)	Bolt Holt Fitting ⌀ (mm)	Load Capacity (kg) 4 km/h
M2100PBRSwivel	Top Plate	100	30	126	37	102x84	80x60	9x14			70
M2125PBRSwivel	Top Plate	125	37	151	35	102x84	80x60	11x15			100
M2150PBRSwivel	Top Plate	150	50	190	40	135x105	105x80	11x15			150
M2200PBRSwivel	Top Plate	200	50	232	49	135x105	105x80	11x15			180
M2100PBRFRigid	Top Plate	100	30	126	0	102x84	80x60	9x14			70
M2125PBRFRigid	Top Plate	125	37	151	0	102x84	80x60	11x15			100
M2150PBRFRigid	Top Plate	150	50	190	0	135x105	105x80	11x15			150
M2200PBRFRigid	Top Plate	200	50	232	0	135x105	105x80	11x15			180
M2100PBRBSwivel with Total Brake	Top Plate	100	30	126	37	102x84	80x60	9x14			70
M2125PBRBSwivel with Total Brake	Top Plate	125	37	151	35	102x84	80x60	11x15			100
M2150PBRBSwivel with Total Brake	Top Plate	150	50	190	40	135x105	105x80	11x15			150
M2200PBRBSwivel with Total Brake	Top Plate	200	50	232	49	135x105	105x80	11x15			180
M2100PBRTSwivel	Threaded Stem	100	30	126	37				M12x30		70
M2125PBRTSwivel	Threaded Stem	125	37	151	35				M12x30		100
M2150PBRTSwivel	Threaded Stem	150	50	190	40				M12x30		150
M2200PBRTSwivel	Threaded Stem	200	50	232	49				M12x30		180
M2100PBRTBSwivel with Total Brake	Threaded Stem	100	30	126	37				M12x30		70
M2125PBRTBSwivel with Total Brake	Threaded Stem	125	37	151	35				M12x30		100
M2150PBRTBSwivel with Total Brake	Threaded Stem	150	50	190	40				M12x30		150
M2200PBRTBSwivel with Total Brake	Threaded Stem	200	50	232	49				M12x30		180
M2100PBROSwivel	Bolt Hole	100	30	126	37					10/16	70
M2125PBROSwivel	Bolt Hole	125	37	151	35					10/16	100
M2150PBROSwivel	Bolt Hole	150	50	190	40					10/16	150
M2200PBROSwivel	Bolt Hole	200	50	232	49					10/16	180
M2100PBROBSwivel with Total Brake	Bolt Hole	100	30	126	37					10/16	70
M2125PBROBSwivel with Total Brake	Bolt Hole	125	37	151	35					10/16	100
M2150PBROBSwivel with Total Brake	Bolt Hole	150	50	190	40					10/16	150
M2200PBROBSwivel with Total Brake	Bolt Hole	200	50	232	49					10/16	180

Wheel & Bracket

Wheel Construction	One-Piece
Wheel Tread Material	Black rubber
Wheel Core Material	Plastic
Bearing Type	Roller Bearing
Bracket Material	Steel
Bracket Construction	Pressed
Surface Treatment	White Zinc Plated
Salt Spray Test Duration	48 h
Wheel Tread Hardness	80 ± 5 Shore A

Performance & Environment

Temperature Resistance	-20°C to +70°C
Rolling Resistance	Low
Suitable Floor Surface	Concrete, Resin / Epoxy, Tile, Vinyl / PVC
Suitable Floor Conditions	Smooth, Slightly Uneven, Uneven, With Obstacles
