eight light-duty caster wheels in top plate mounting style, with brown color TPE wheel and silver color zinc plated metal bracket.

L5V series light-duty TPE caster wheels

Send your load, wheel size, mounting type and quantity for a faster recommendation.

SERIESL5V series | 45-65 kg capacity SeriesView all L5V series | 45-65 kg capacity casters PRODUCT FAMILYVersatile light-duty castersView all Versatile light-duty casters WHEEL MATERIALTPEView all casters with TPE wheels ALL PRODUCTSCaster WheelsView all products

Model & Dimensions

Product Code / Configuration	Mounting Type	Wheel Ø (mm)	Wheel Width (mm)	Mounting Height (mm)	Offset (mm)	Top Plate Size (mm)	Bolt Hole Spacing (mm)	Bolt Hole Size (mm)	Threaded Stem (mm)	Bolt Holt Fitting ⌀ (mm)	Grip Ring Stem (mm)	Threaded Stem + Round expander (mm)	Threaded Stem + Square Expander (mm)	Load Capacity (kg) 4 km/h
L5V050TPESwivel	Top Plate	50	23	74	24	60x49	45.5x32.5	6.3						45
L5V063TPESwivel	Top Plate	63	23	88	27	71x58	54.5x38.5	8.3						50
L5V075TPESwivel	Top Plate	75	23	100	28	71x58	54.5x38.5	8.3						60
L5V100TPESwivel	Top Plate	100	25	127	28	71x58	54.5x38.5	8.3						65
L5V050TPEFRigid	Top Plate	50	23	74	0	60x49	45.5x32.5	6.3						45
L5V063TPEFRigid	Top Plate	63	23	88	0	71x58	54.5x38.5	8.3						50
L5V075TPEFRigid	Top Plate	75	23	100	0	71x58	54.5x38.5	8.3						60
L5V050TPEBSwivel with Total Brake	Top Plate	50	23	74	24	60x49	45.5x32.5	6.3						45
L5V063TPEBSwivel with Total Brake	Top Plate	63	23	88	27	71x58	54.5x38.5	8.3						50
L5V075TPEBSwivel with Total Brake	Top Plate	75	23	100	28	71x58	54.5x38.5	8.3						60
L5V100TPEBSwivel with Total Brake	Top Plate	100	25	127	28	71x58	54.5x38.5	8.3						65
L5V050TPETSwivel	Threaded Stem	50	23	74	24				M10x25					45
L5V063TPETSwivel	Threaded Stem	63	23	88	27				M10x25					50
L5V075TPETSwivel	Threaded Stem	75	23	100	28				M10x25					60
L5V100TPETSwivel	Threaded Stem	100	25	127	28				M10x25					65
L5V050TPETBSwivel with Total Brake	Threaded Stem	50	23	74	24				M10x25					45
L5V063TPETBSwivel with Total Brake	Threaded Stem	63	23	88	27				M10x25					50
L5V075TPETBSwivel with Total Brake	Threaded Stem	75	23	100	28				M10x25					60
L5V100TPETBSwivel with Total Brake	Threaded Stem	100	25	127	28				M10x25					65
L5V050TPEOSwivel	Bolt Hole	50	23	74	24					10.5/12.5				45
L5V063TPEOSwivel	Bolt Hole	63	23	88	27					10.5/12.5				50
L5V075TPEOSwivel	Bolt Hole	75	23	100	28					10.5/12.5				60
L5V100TPEOSwivel	Bolt Hole	100	25	127	28					10.5/12.5				65
L5V050TPEOBSwivel with Total Brake	Bolt Hole	50	23	74	24					10.5/12.5				45
L5V063TPEOBSwivel with Total Brake	Bolt Hole	63	23	88	27					10.5/12.5				50
L5V075TPEOBSwivel with Total Brake	Bolt Hole	75	23	100	28					10.5/12.5				60
L5V100TPEOBSwivel with Total Brake	Bolt Hole	100	25	127	28					10.5/12.5				65
L5V050TPESGSwivel	Grip Ring	50	23	74	24						11x22/35			45
L5V063TPESGSwivel	Grip Ring	63	23	88	27						11x22/35			50
L5V075TPESGSwivel	Grip Ring	75	23	100	28						11x22/35			60
L5V100TPESGSwivel	Grip Ring	100	25	127	28						11x22/35			65
L5V050TPESGBSwivel with Total Brake	Grip Ring	50	23	74	24						11x22/35			45
L5V063TPESGBSwivel with Total Brake	Grip Ring	63	23	88	27						11x22/35			50
L5V075TPESGBSwivel with Total Brake	Grip Ring	75	23	100	28						11x22/35			60
L5V100TPESGBSwivel with Total Brake	Grip Ring	100	25	127	28						11x22/35			65
L5V050TPERP-22(25)Swivel	Round Expander	50	23	74	24						11x22/35			45
L5V063TPERP-22(25)Swivel	Round Expander	63	23	88	27							M12x60+M22/25		50
L5V075TPERP-22(25)Swivel	Round Expander	75	23	100	28							M12x60+M22/25		60
L5V100TPERP-22(25)Swivel	Round Expander	100	25	127	28							M12x60+M22/25		65
L5V050TPERP-22(25)BSwivel with Total Brake	Round Expander	50	23	74	24							M12x60+M22/25		45
L5V063TPERP-22(25)BSwivel with Total Brake	Round Expander	63	23	88	27							M12x60+M22/25		50
L5V075TPERP-22(25)BSwivel with Total Brake	Round Expander	75	23	100	28							M12x60+M22/25		60
L5V100TPERP-22(25)BSwivel with Total Brake	Round Expander	100	25	127	28							M12x60+M22/25		65
L5V050TPEQP-22.3-(26.7)Swivel	Square Expander	50	23	74	24								M12x60+22.3/26.7	45
L5V063TPEQP-22.3-(26.7)Swivel	Square Expander	63	23	88	27								M12x60+22.3/26.7	50
L5V075TPEQP-22.3-(26.7)Swivel	Square Expander	75	23	100	28								M12x60+22.3/26.7	60
L5V100TPEQP-22.3-(26.7)Swivel	Square Expander	100	25	127	28								M12x60+22.3/26.7	65
L5V050TPEQP-22.3-(26.7)BSwivel with Total Brake	Square Expander	50	23	74	24								M12x60+22.3/26.7	45
L5V063TPEQP-22.3-(26.7)BSwivel with Total Brake	Square Expander	63	23	88	27								M12x60+22.3/26.7	50
L5V075TPEQP-22.3-(26.7)BSwivel with Total Brake	Square Expander	75	23	100	28								M12x60+22.3/26.7	60
L5V100TPEQP-22.3-(26.7)BSwivel with Total Brake	Square Expander	100	25	127	28								M12x60+22.3/26.7	65

Wheel & Bracket

Wheel Construction	Tread on Core
Wheel Tread Material	TPE
Wheel Core Material	Plastic
Bearing Type	Ball Bearing, Plain Bore
Bracket Material	Steel
Bracket Construction	Pressed
Surface Treatment	White Zinc Plated
Salt Spray Test Duration	48 h
Wheel Tread Hardness	75 ± 5 Shore A

Performance & Environment

Temperature Resistance	-20°C to +60°C
Rolling Resistance	High
Suitable Floor Surface	Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Wood
Suitable Floor Conditions	Smooth, Slightly Uneven, Uneven
