| Product Code / Configuration | Mounting Type | Wheel Ø (mm) | Wheel Width (mm) | Mounting Height (mm) | Offset (mm) | Top Plate Size (mm) | Bolt Hole Spacing (mm) | Bolt Hole Size (mm) | Threaded Stem (mm) | Bolt Hole Fitting ⌀ (mm) | Load Capacity (kg) 3 km/h |
|---|---|---|---|---|---|---|---|---|---|---|---|
| L8D050PPSwivel | Top Plate | 50 | 19 | 72 | 26 | 60x60 | 48x48 | 7x12 | 50 | ||
| L8D075PPSwivel | Top Plate | 75 | 25 | 100 | 28 | 65x65 | 45x45 | 7x12 | 60 | ||
| L8D050PPFRigid | Top Plate | 50 | 19 | 72 | 0 | 60x60 | 48x48 | 7x12 | 50 | ||
| L8D075PPFRigid | Top Plate | 75 | 25 | 100 | 0 | 65x65 | 45x45 | 7x12 | 60 | ||
| L8D050PPBSwivel with Total Brake | Top Plate | 50 | 19 | 72 | 26 | 60x60 | 48x48 | 7x12 | 50 | ||
| L8D075PPBSwivel with Total Brake | Top Plate | 75 | 25 | 100 | 28 | 65x65 | 45x45 | 7x12 | 60 | ||
| L8D050PPTSwivel | Threaded Stem | 50 | 19 | 72 | 26 | M12 x25 | 50 | ||||
| L8D075PPTSwivel | Threaded Stem | 75 | 25 | 100 | 28 | M12 x25 | 60 | ||||
| L8D050PPTBSwivel with Total Brake | Threaded Stem | 50 | 19 | 72 | 26 | M12 x25 | 50 | ||||
| L8D075PPTBSwivel with Total Brake | Threaded Stem | 75 | 25 | 100 | 28 | M12 x25 | 60 | ||||
| L8D050PPOSwivel | Bolt Hole | 50 | 19 | 72 | 26 | 10 | 50 | ||||
| L8D075PPOSwivel | Bolt Hole | 75 | 25 | 100 | 28 | 10 | 60 | ||||
| L8D050PPOBSwivel with Total Brake | Bolt Hole | 50 | 19 | 72 | 26 | 10 | 50 | ||||
| L8D075PPOBSwivel with Total Brake | Bolt Hole | 75 | 25 | 100 | 28 | 10 | 60 |
| Wheel Construction | One-Piece |
|---|---|
| Wheel Material | Plastic |
| Bearing Type | Plain Bore |
| Bracket Material | Steel |
| Bracket Construction | Pressed |
| Surface Treatment | White Zinc Plated |
| Salt Spray Test Duration | 48 h |
| Wheel Tread Hardness | 65 ± 3 Shore D |
| Temperature Resistance | -10°C to +70°C |
|---|---|
| Rolling Resistance | Low |
| Suitable Floor Surface | Concrete, Resin / Epoxy, Tile, Vinyl / PVC, Carpet, Asphalt |
| Suitable Floor Conditions | Smooth, Slightly Uneven |
| Antistatic | × |
|---|---|
| Conductive | × |
| Non-Marking | ✓ |
| Non-Staining | ✓ |
